Column base type D in concrete
Order no.: 19620080
EAN: 4019346510001
Anwendungen
| Are you a customer or a new customer? (Specialist trade) | ||
| For more information about our products, orders, invoices and promotions, log in to our new shop system (account above). |
| Netto Gewicht Kg: | 193 |
| DC Statik: | JA |
| Made in Germany: | JA |
| Gruppe: | Pfostentraeger |
| Statics diagram: | Pfostentraeger |
| ETA: | ETA-16 0550 |
| Use class: | NKL3 |
| Ø 11 mm: | 4 |
| Ø 9 mm: | 1,00 |
| Beam width: | 80 |
| Thickness of support plate: | 6 |
| Mandrel height: | 120 |
| Mandrel Ø: | 20 |
| Dolle height: | 374 |
| Dolle Ø: | 20 |
| Material: | S 235 fz |
